Sina Ekato
1 / 1
| Specs (L) | D(mm) | D1(mm) | H1(mm) | H2 (mm) | H3 (mm) | H(mm) | DN(mm) |
| 200 | 700 | 800 | 400 | 800 | 235 | 1085 | 32 |
| 500 | 900 | 1000 | 640 | 1140 | 270 | 1460 | 40 |
| 1000 | 1100 | 1200 | 880 | 1480 | 270 | 1800 | 40 |
| 2000 | 1400 | 1500 | 1220 | 1970 | 280 | 2300 | 40 |
| 3000 | 1600 | 1700 | 1220 | 2120 | 280 | 2450 | 40 |
| 4000 | 1800 | 1900 | 1250 | 2250 | 280 | 2580 | 40 |
| 5000 | 1900 | 2000 | 1500 | 2550 | 320 | 2950 | 50 |
According to storage capacity, the storage tanks are classified into tanks of 100-15000L. For storage tanks with storage capacity more than 20000L, it is suggested to use outdoor storage. The storage tank is made of SUS316L or 304-2B stainless steel and has good heat preservation performance.
Material: Sanitary stainless steel 304/316
Volume: 50L-20000L
Design Pressure: 0.1Mpa~1.0Mpa
Applicable range: Used as liquid storage tank, liquid composing tank, temporary storage tank and water storage tank etc. Ideal in fields such as foods, dairy products, fruit juice beverages, pharmacy, chemical industry and biological engineering etc.
Each machine is carefully made to ensure satisfaction. Our products in the production process are strictly monitored to provide you with the best quality. We focus on long-term cooperation by offering reliable value across all types. If you have any questions, do not hesitate to ask us.
The tanks are constructed using high-quality sanitary stainless steel, specifically SUS304 or SUS316L, ensuring durability and hygiene.
Standard capacities range from 50L to 15,000L. For requirements exceeding 20,000L, outdoor storage solutions are recommended.
Yes, they are ideal for food, dairy products, beverages, pharmacy, chemical industries, and biological engineering due to their sanitary design.
The interior walls use arc transitions for all joints to eliminate dead corners, and the system is equipped with CIP (Clean-In-Place) spraying heads.
Yes, various features such as manholes, ladders, liquid level controllers, and thermometers can be configured based on specific customer requirements.
The tanks are designed to operate within a pressure range of 0.1Mpa to 1.0Mpa.
