For material of super high viscosity (above 50,000 C.P.S), the high viscosity vacuum emulsifying homogenizer is highly recommended. Raw materials can be directly sucked into the groove by the machine. The equipment is integrated with vacuum, hydraulic pressure, heating, cooling, and other multi-functions.
The advantage of the homogenizing emulsifier is its ability to handle a variety of product materials. The lid stirring homogenizer is connected with the frame using a hydraulic system for easy lifting and convenient cleaning. Our equipment ranges from laboratory scale to large tonnage processing capacities, all utilizing optimized homogenizing structures.
Approximately 80% of our main components are provided by world-renowned suppliers. Through long-term cooperation, we provide high-quality products with effective performance guarantees.
| Model | Capacity | Homogenizer Motor | Stir Motor | Dimension (mm) | Total Power (KW) | Limit Vacuum (Mpa) | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| KW | r/min | KW | r/min | L | W | H | Steam | Electric | |||
| SME-D5 | 5L | 0.37 | 3000 | 0.18 | 63 | 1260 | 540 | 1600/1850 | 2 | 5 | -0.09 |
| SME-D10 | 10L | 0.75 | 3000 | 0.37 | 63 | 1300 | 580 | 1600/1950 | 3 | 6 | -0.09 |
| SME-D50 | 50L | 3 | 3000 | 1.1 | 63 | 2600 | 2250 | 1950/2700 | 9 | 18 | -0.09 |
| SME-D100 | 100L | 4 | 3000 | 1.5 | 63 | 2750 | 2380 | 2100/2950 | 13 | 32 | -0.09 |
| SME-D200 | 200L | 5.5 | 3000 | 2.2 | 63 | 2750 | 2750 | 2350/3350 | 15 | 45 | -0.09 |
| SME-D300 | 300L | 7.5 | 3000 | 2.2 | 63 | 2900 | 2850 | 2450/3500 | 18 | 49 | -0.085 |
| SME-D500 | 500L | 11 | 3000 | 4 | 63 | 3650 | 3300 | 2850/4000 | 24 | 63 | -0.08 |
| SME-D1000 | 1000L | 15 | 3000 | 5.5 | 63 | 4200 | 3650 | 3300/4800 | 30 | 90 | -0.08 |
| SME-D2000 | 2000L | 15 | 3000 | 7.5 | 63 | 4850 | 4300 | 3800/5400 | 40 | - | -0.08 |
| Note: In case of data inconsistency due to technical improvement, the real object shall prevail. | |||||||||||
