This system occupies little space, is easy to operate, and has a wide application range. When used for disposing industrial water, the reverse osmosis device does not consume large amounts of acids and alkalis, ensuring no secondary pollution while maintaining low operation costs.
✓
Reverse osmosis desalting rate >99%, machine desalting rate >97%.
✓
98% of organic matters, colloids, and bacteria can be removed.
✓
High operation automation: unattended, automatic stop/start based on water sufficiency.
✓
Over 90% of components are high-quality imported parts.
Technical Advantages
1
Small volume, simple operation, and wide application range.
2
No consumption of large amounts of acid or alkali; environmentally friendly with low operating costs.
3
Output water conductivity: One stage ≤ 10 μs/cm; Two stage 2-3 μs/cm; EDI ≤ 0.5 μs/cm.
4
IC microcomputer controller for automatic flushing of RO film and online conductivity display.
DUBAI Project - 2000L/Hour
Applications
Electronic Industry: Integrated circuits, silicon wafers, display tubes.
Pharmaceutical: Large infusion, injections, tablets, biochemical products.
Chemical Process: Circulating water, chemical manufacturing.
Electric Power: Thermal power boilers, low-pressure boiler power systems.
Food & Beverage: Purified drinking water, beverages, beer, alcohol.
Desalination: Seawater and saline water for islands, ships, and drilling platforms.
Process Flowchart (Two-stage Type)
Raw water → Raw water tank → Raw water pump → Sand filter → Carbon filter → Safety filter → High pressure pump → One stage RO → Middle water tank → High pressure pump → Two stage RO → Stainless steel pure water tank → Pure water pump → Using pure water point
SRI LANKA Project - 1000L/Hour
UK Project - 1000L/Hour
SOUTH AFRICA - 2000L/HOUR
DUBAI Project - 3000L/Hour
SYRIA PROJECT - 500L/HOUR
KUWAIT PROJECT - 1000L/HOUR
CG-Anion Cation Mixing Bed
Ozone Generator
Ultraviolet Sterilizer
CG-EDI-6000L/Hour
Technical Specifications
| Model |
Capacity (T/H) |
Power (KW) |
Recovery (%) |
1-stage Cond. (μs/cm) |
2-stage Cond. (μs/cm) |
EDI Cond. (μs/cm) |
| R0-500 | 0.5 | 0.75 | 55-75 | ≤10 | 2-3 | ≤0.5 |
| R0-1000 | 1.0 | 2.2 | 55-75 | ≤10 | 2-3 | ≤0.5 |
| R0-2000 | 2.0 | 4.0 | 55-75 | ≤10 | 2-3 | ≤0.5 |
| R0-3000 | 3.0 | 5.5 | 55-75 | ≤10 | 2-3 | ≤0.5 |
| R0-5000 | 5.0 | 7.5 | 55-75 | ≤10 | 2-3 | ≤0.5 |
| R0-10000 | 10.0 | 11 | 55-75 | ≤10 | 2-3 | ≤0.5 |
| No |
Item |
Data |
| 1 | Description | Pure water treatment purifying machine |
| 2 | Voltage | AC380V-3phase |
| 3 | Component | Sand + Carbon + Soften + Precision + RO filters |
| 4 | Capacity | 500L/H - 5000L/H (Customizable) |
| 5 | Control | Button or PLC + Touch screen |
Frequently Asked Questions
What is the desalination efficiency of this RO system?
The system features a reverse osmosis desalination rate of over 99%, with the overall machine desalination rate reaching ≥97%.
Is the operation fully automated?
Yes, the system is highly automated. It can operate unattended, automatically stopping when water is sufficient and starting when water is needed.
What kind of contaminants can this system remove?
It effectively removes 98% of organic matters, colloids, bacteria, and other impurities from the raw water.
Does the system require chemical cleaning frequently?
The device is designed to avoid large consumption of acids and alkalis during industrial water treatment, reducing secondary pollution and operating costs.
Can the capacity of the machine be customized?
Yes, while standard models range from 500L/H to 20,000L/H, capacities between 500-5000L/H and above can be customized to meet specific project needs.
What are the electrical requirements for the system?
The standard system operates on AC380V 3-phase power, which is typical for industrial water treatment equipment.
